Niner JET 9 RDO 29 - 4-Star - XT - Carbon-Red - Medium - Demo1

Every Ex-Demo bike is priced to reflect damage and comes with a 6 Month Cambria Bike Warranty. Buy with confidence and rest assured that prior to sale each bike must pass the following rigorous checks:

✓ - Components Inspected
✓ - Drivetrain Cleaned
✓ - Gears Indexed
✓ - Frame Integrity Checked
✓ - Suspension Adjusted
✓ - Wheels Trued

Experience trail riding like never before with the Niner JET 9 RDO 29 - 4-Star XT. Crafted from lightweight yet durable carbon, this bike features a 120mm rear travel and a 29-inch wheel setup for superior speed and stability on the trail. Equipped with Shimano XT components, a responsive Fox shock, and titanium frame guards, it delivers exceptional performance, precision, and reliability. Whether you're seeking adventure or pushing your limits, the JET 9 RDO 29 is your ultimate trail companion.

Features:

• Bottom Bracket: 73mm BSA threaded with ISCG 05 tabs
• Shock Hardware: M8 x 22mm, 184mm x 44mm
• Seat Post: 30.9mm diameter, 400mm length recommended
• Dropper Post: Compatible with internal and external routing
• Seat Collar: 34.9mm
• Headset: Tapered, 1.125" x 1.5" zero-stack, includes Cane Creek ZS44/28.6 and ZS56/40
• Rear Spacing: Boost 148mm x 12mm
• Bottle Mounts: One inside the front triangle on all sizes
• Frame Guards: Titanium
• Tire Compatibility: Up to 29x2.6" or 27.5x3.0" (size varies by brand, some tires may not fit)
• Chainring Recommendations:
  • SRAM: 26/39T or lower (2x boost chain rings)
  • SRAM 1x Boost: max 36T chain ring with 168mm Q factor
  • Shimano XT M8000 Boost: 28/38T or lower (2x)
  • Shimano XTR M9020 Boost: 36T or lower (1x)

Niner JET 9 RDO 29" 4-Star XT Bike Specifications

Riding Type: Trail
Rider: Unisex

---

Sizes & Geometry

• Sizes: XS, SM, MD, LG, XL
• Wheel Size: 29"

Frame & Suspension

• Frame Material: RDO Carbon Fiber with titanium frame guards
• Frame Details: RDO Carbon compaction
• Rear Travel: 120mm
• Rear Shock: FOX Float DPS Factory EVOL, 3-position, 184mm x 44mm
• Fork: FOX 34 Float Factory FIT4, 3-position with adjust, Kashima coat, 110x15mm axle
• Fork Travel: 140mm
• Head Tube Diameter: Tapered (1.125" top, 1.5" bottom)
• Headset: Niner internal, zero-stack, ZS44/28.6 | ZS56/40
• Dropouts / Hub Dimensions: 148x12mm Boost rear, 110x15mm front

---

Handlebar & Stem

• Handlebar: Race Face Next, 760mm width, 20mm rise, 35mm clamp
• Stem: Race Face Aeffect, 35mm clamp

Grips

• Niner Grrrips, lock-on

Brakes

• Shimano XT M8000, RT86 Ice Tech rotors (180mm front, 160mm rear), Ice Tech pads
• Brake Levers: Shimano XT M8000

Drivetrain

• Configuration: 1x
• Shifters: Shimano XT M8000, 11-speed, I-Spec II
• Front Derailleur: N/A
• Rear Derailleur: Shimano XT M8000 GS, 11-speed, Shadow Plus
• Chainguide: N/A
• Cranks: Race Face Turbine
• Chainrings: Race Face Turbine, 32 tooth
• Bottom Bracket: Race Face BSA, 73mm
• Chain: Shimano XT HG-701, 11-speed
• Cassette: Shimano XT M8000, 11-46 tooth, 11-speed

Wheels & Tires

• ENVE M60+ rims with DT Swiss 350 hubs (28 hole)
• Tires: Maxxis Rekon + DC/EXO/TR, 27.5" x 2.8"

Saddle & Seatpost

• Saddle: Niner custom, CrMo rails, Niner graphic
• Seatpost: KS Lev Integra
• Seatpost Diameter: 30.9mm
• Seatpost Clamp: Standard single bolt

---

Additional Features & Options

• Bottle Cage Mounts: Yes (single)
• Max Tire Size: 29" x 2.5"
• Colors: Blaze Yellow, Satin/Carbon/Slate/Red
• Suspension System: CVA
• Wheels Upgrade: ENVE M60+ rims with DT Swiss 350 hubs (28 hole)
• Routing: Internal and external dropper post routing
• Electronic Drivetrain Wiring: Compatibility (including integrated battery storage in the frame)
